This part fits the following models:
Nissan Patrol Hardtop 3.2 D (1984 - 1998) 81kW
Nissan Patrol Station Wagon 3.2 D (1979 - 1989) 70kW
Nissan Patrol Hardtop 3.2 D (1979 - 1989) 70kW
Equivalent Part Numbers:
System Requirements
Cone Pitch: 120Failure Moment [Nm]: 35Fitting Depth [mm]: 17Glow Plug Type: Pencil-type Glow Plug; after-glow capableOverall Length [mm]: 68Port Type: M4/2NmRated Current [A]: 5.5Spanner Size: 12 mmThread Size: M 10x1.25Tightening Torque [Nm]: 15Voltage [V]: 24
Nissan Patrol Hardtop 3.2 D (1984 - 1998) 81kW
Nissan Patrol Station Wagon 3.2 D (1979 - 1989) 70kW
Nissan Patrol Hardtop 3.2 D (1979 - 1989) 70kW
Equivalent Part Numbers:
System Requirements
Cone Pitch: 120Failure Moment [Nm]: 35Fitting Depth [mm]: 17Glow Plug Type: Pencil-type Glow Plug; after-glow capableOverall Length [mm]: 68Port Type: M4/2NmRated Current [A]: 5.5Spanner Size: 12 mmThread Size: M 10x1.25Tightening Torque [Nm]: 15Voltage [V]: 24
- Cone Pitch: 120
- Connector type: M4 / 2 Nm
- Failure Moment [Nm]: 35
- Fitting Depth [mm]: 17
- Overall Length [mm]: 68
- Rated Current [A]: 5,5
- Spanner Size: 12 mm
